Used Durr MEGTEC Systems Clean Switch 30,000 Regenerative Thermal Oxidizer For Sale

Durr Environmental-MEGTEC Systems 30,000 scfm regenerative thermal oxidizer (RTO) in good condition. This unit treated emissions from a heatset web offset printing press.

  • Maximum design flow: 30,000 scfm @ 350° F process exhaust temp.
  • Two media chamber design with structured/saddle media mix
  • 95% effective heat exchanger
  • Rotary Switching Valve – for flow direction changes thru the media [pneumatic drive (single cylinder)]
  • Main exhaust fan with 250 hp motor
  • Variable Speed Drive
  • Nozzle Mix Burner- Maxon Kinemax 4
  • VOC Entrapment feature for high VOC destruction/visible emission reduction
  • Hot side bypass feature for high VOC concentration airstreams
  • Exhaust stack; 40′ from grade
  • Air Conditioned/Heated Control Room
  • Allen Bradley SLC 5/05 PLC with Panelview Plus 1000 HMI(upgrade available)


See case studies of Refurbished RTO units by Kono Kogs, or contact our team to speak with an expert.

Equipment Specifications

  • Type of Equipment:
  • Brand:
    Dürr Environmental‍
  • Approx. Footprint:
    37' long, 18' wide, 24' H (excluding stack; including main fan)
  • Weight:
    168,500 lbs (including ceramic media)
  • Electrical Requirements:
    460/3/60, 325 FLA (preliminary estimate)
  • Gas Requirements:
    3,600 cfh max @ 5+/-0.25 psig @ 1000 btu/CF
  • Compressed Air Requirements:
    360 CFH @ 80 psig and -40 deg F dew point
