Durr MEGTEC Systems Clean Switch 25,000 Used Regenerative Thermal Oxidizer (RTO)

Durr MEGTEC Systems Clean Switch 25,000 Used Regenerative Thermal Oxidizer (RTO)

Durr MEGTEC Clean Switch regenerative thermal oxidizer (RTO) with 25,000 scfm capacity for sale; including performance and parts warranty. Previously treated paint spray booth emissions from a metal coating line.

Request a Quote
No items found.

Equipment Details

Used Durr MEGTEC Systems Clean Switch 25,000 Regenerative Thermal Oxidizer For Sale

Durr Environmental-MEGTEC Systems 25,000 scfm used Regenerative Thermal Oxidizer (RTO). Treated paint spray booth emissions from a metal coating line.  Clean Switch RTOs are very well built with a small footprint (21′ x 35′). RTO was shut down in March 2019 and has been idle since. In very good condition, but many mechanical components will need replacement due to length of idle time. Available immediately.

Rotary switching valve, structured ceramic media, Allen Bradley SLC 5/03 PLC, 35-foot free-standing stack.


  • Maximum design flow: 25,000 scfm @ 250° F process exhaust temp.
  •
  • Two media chamber design with structured ceramic media
  •
  • 95% effective heat exchanger
  •
  • Rotary Switching Valve – for flow direction changes thru the media (electric drive)
  •
  • Main exhaust fan with 250 hp TEFC motor
  •
  • Mitsubishi Variable Speed Drive
  •
  • Nozzle Mix Burner- Maxon Kinemax
  •
  • Air Conditioned/Heated Control Room     Allen Bradley SLC 5/03 PLC with Allen Bradley Panelview 1000 touchscreen
  •

See case studies of Refurbished RTO units by Kono Kogs, or contact our team to speak with an expert.

Equipment Specifications

  • Type of Equipment:
  • Brand:
    Dürr Environmental‍
  • Approx. Footprint:
    Typical CS-25 Layout: 35' long, 20' wide, 27' H (excluding stack; including main fan)
  • Weight:
    118,000 lbs (including ceramic media)
  • Electrical Requirements:
    460/3/60, 330 FLA (preliminary estimate)
  • Gas Requirements:
    3,000 cfh max @ 5+/-0.25 psig @ 1000 btu/CF
  • Compressed Air Requirements:
    300 CFH @ 90 psig and -40 deg F dew point
